Since 1935, Snap-Tite has thrived on application problem solving and design versatility. This range offers more combinations, sizes and variations of quick disconnect couplings than any other manufacturer in the world today. Innovator of the Dry Break Coupling, Snap-Tite Quick Disconnect Couplings set the industry standard. Performance without compromise is the Snap-Tite promise. Applications include: General Purpose, Agriculture, Mobile Equipment, Construction Equipment, In-Plant Hydraulics, Chemicals, Corrosive Materials, Water Blast, High Pressure Cleaning, Off Shore, Oil Well, Heavy Duty Applications, CNG and Gas Industries.

General Purpose, Agriculture, Mobile Equipment
61 Series

61 Series

  • ISO7241-1 Series A interchange
  • W.P. up to 4,600psi
  • Available in Plated Steel construction
72 Series

72 Series

  • ISO7241-1 Series B interchange
  • W.P. up to 7,500psi
  • Steel, Brass or Stainless Steel
H Series

H, IH, PH Series

  • End fitting and valve versatility
  • W.P. up to 11,000psi
  • Steel, Brass, Aluminium or S/S
60 Series

60 series

  • Positive ball-lock connection
  • W.P. up to 3000psi
  • Plated steel construction
Construction & Mobile Equipment, In-Plant Hydraulics
71 Series

71 Series

  • Flush face eliminates fluid loss and air inclusion
  • W.P. up to 10,000psi
  • Heavy duty - Steel or S/S construction

23 Series

  • Drybreak coupling with safety sleeve-lock
  • W.P. up to 3,000psi
  • Plated steel construction
74 Series

74 Series

  • Meets ISO16028 Specification
  • W.P. up to 4,600psi
  • Plated steel construction

59 Series

  • Quick-to-Connect Quick Disconnect
  • No-spill, drybreak, flat-face design
  • 550 bar working pressure
  • Plated steel construction
Chemical, Corrosive Materials

25 series

  • Teflon® or KEL F® seals
  • W.P. up to 1,000psi
  • 316 Stainless Steel construction

29 series

  • Exceeds MIL-C-7413B specifications
  • W.P. up to 5,500psi
  • Aluminium or 316 Stainless Steel

K Series

  • Temp range -240°C to 240°C
  • W.P. up to 1,000psi
  • Stainless Steel or exotic alloy construction
Off Shore, Oil Well, Heavy Duty Applications

75 Series

  • Connect under pressure. Norske Veritas approved
  • W.P. up to 5,000psi
  • Plated Steel or 316 Stainless Steel construction

77 Series

  • Dog lock positive connection
  • W.P. up to 36,000psi
  • Plated Steel or Stainless Steel construction

78 Series

  • Bonded valve seal. Wing or Hex nut
  • >W.P. up to 3,000psi
  • Brass construction
Water Blast, High Pressure Cleaning

56 Series

  • Dog lock positive connection.
  • Interchangeable with Parker and Aeroquip Series
  • W.P. up to 12,000psi
  • High strength plated steel construction

73 Series

  • Positive locking collar prevents accidental disconnection
  • W.P. up to 43,500psi
  • Stainless Steel construction


CNG, Gas appliances
GF Series

GF Series

  • Thermal shut off for safety.
  • Certified specification ANSI Z21.41
  • W.P. to 0.5psi
  • Brass construction

Compressed Natural Gas Products

  • Natural gas vehicle nozzles
  • Natural gas vehicle receptacles
  • Compressed natural gas inline breakaway
  • Compressed natural gas (CNG) check valve
  • Nozzles cannot be disconnected manually while under internal pressure greater than 250psi (25bar)


Vacuum Applications
E Series

E, EA Series

  • High Temperature sealing and hard Vacuums down to 29.72"Hg
  • W.P. up to 3,000psi
  • Plated Steel, Brass, Aluminium or 316 Stainless Steel construction
