Battery & Fridge Trays

RV designers are master at making the most of every inch of space. Kwikee helps by making products that allow RV owners more access to these spaces. No more twisting or bending, just effortless access with Kwikee trays. Load, maintain and service your batteries, LP tanks, freezer and anything else you need to store. Designed to last, Kwikee Utility Trays are constructed of heavy gauge steel. Ball bearing and roller bearing slides give the tray sliding strength and smooth operation. Available in a wide assortment of sizes and styles, Kwikee Trays will give you easy access to all your essentials.

Kwikee Storage Trays

Battery Trays

  • Battery trays completely assembled; ready to bolt in.
  • Safety latch holds tray fully retracted or fully extended.
  • Hold 1 to 8 batteries.
  • See size chart below. Outside dimension for compartment fit
TRAY PART # WIDTH DEPTH HEIGHT
905 700 010   15-1/2” or 384mm 15-1/8” or 384mm 3-3/8” or 85mm
905 707 000 25-1/8” or 638mm 24-13/16” or 630mm 3-3/16” or 80mm
905 708 000   22-1/4” or 565mm 15 1/4” or 387mm 3-1/16” or 77mm
905 711 000   24-9/16" or 623mm 18-3/8" or 466mm 3-3/16” or 80mm
905 728 000 23-7/16” or 595mm 12” or 304mm 5-1/4” or 133mm

Fridge Trays

  • Make access to freezer and extra refrigerator storage more convenient to use.
  • Opening in bottom of tray accommodates drainage and circulation.
  • Ball bearing and roller bearing movement.
  • Safety latch mechanism locks slide for safe storage.
  • Tray comes assembled, ready to bolt in.
  • See size chart below. Inside dimension is for freezer/refrigerator size. Outside dimension is for compartment fit.
No.

Outside Dimensions

Inside Dimensions
Wt

W
D
H
W
D
90 55 70 00

33 3/4"
28 1/ 16"
3 11 /16'
31 1/2"
20 1/8"
200 lb
857 mm
712 mm
93 mm
800 mm
511 mm
90 kg
90 55 71 00 0

16 3/4"
28 1/ 16"
3 11 /16"
14 1/2"
25 1/2"
200 lb
425 mm
712 mm
93 mm
368 mm
648 mm
90 kg
90 55 72 00

27 1/2"
18 1/ 16"
3 11 /16"
25 1/4"
14 5/8"
200 lb
699 mm
458 mm
93 mm
641 mm
371 mm
90 kg
