Electro Hydrauilc MMC

The Electro-Hydraulic MMC is a reliable system designed to operate multiple movements in the most innovative medical applications. It combines the need of an electro-hydraulic and manual-hydraulic system, with up to 4 manual back up functions if power supply fails. The system enables the user, by means of a selector operated by a handset, to select which cylinder to operate. The selector is integrated in the pump which results in less build-in space and less weight. All available double acting cylinders can be combined, this gives you the flexibility to create the most suitable system for your application.

Features

• Operate up to 12 cylinders (electro-hydraulic) including up to 4 back up functions (manual-hydraulic)
• 1 – 12 double acting hydraulic cylinders: 8,5 and 14 kN push forces
• 2 hoses per cylinder: 1.0 mtr/1.5 mtr/2.0 mtr
• Pump motor 12 V or 24 V
• Electrical part: IP 68
• The selector and the pump are integrated in one bloc. Selector function: manual or electrical. Manual by rotating the shaft, one of the cylinders can be selected. Pump function: manual or electrical. The selected cylinder is extended by pumping the foot pedal down or by handset (electro-hydraulic). The selected cylinder is retracted by pumping the foot pedal down or by handset (electro-hydraulic)

Benefits

• Reduced total cost of ownership
• Proven high quality, product built for long life
• Enhanced performance, high load forces, optimum technology for bariatric needs
• Reliable operating, manual override to ensure operation when power supply fails
• Operating comfort for manual override (selector), easy cylinder selection by means of handset
• Durability, robust system, low risk profile
• Maintenance-free
• Functional Safety, system 100% tested and pre-fi lled, valves with integrated safety function mounted to the cylinder
• Customized solution, system fl exibility to adapt to application needs by using modular components
