Heavy Duty Hydraulic Stabilisation Legs

Power-Packer’s Heavy Duty Series of stabilization legs are the result of a thorough evaluation of the current market needs which require heavy wall tube design, integrated valve blocks, thicker mounting plates, and lift capacities from 59,000 lbs up to 115,000 lbs and static load holding from 150,000 to 225,000 lbs. The mounting bracket can be customized to the specific requirements of the customer application. A variety of foot pads are available in fixed, articulated, and removable styles.

For heavy duty stabilization legs with a stroke greater than 36″, please contact Customer Service for further information on lead times.

Features

• Completely assembled and tested – Outer Tube
• Mount Included
• Mounting Brackets integrated on outer mount tube
• Mounting Brackets can be customized to specific requirements of each customer’s application
• Integrated load holding/ relieving valves
• Dual Guide Rings inside outer mount tube
• Mechanical locking optional: Available with or without
• Strong Capacity
  • Robust design
  • Available in 5”, 6”, and 7” bore sizes
  • 59,000lb – 115,000lb hydraulic lift capacity
  • 10% to 20% side load capacity depending on stroke
• Stroke from 12” to 60”
• SAE Ports standard
• Universal footpad – optional
  • 20 degree Swivel style
  • 14 degree Crane style

Benefits

• Eliminate Contamination
  • O-ring seals in rod head prevent contamination
  • Dual guide rings protect contamination from entering tube wall
• Ease of Assembly
  • Leg shipped complete with mounting bracket already attached
  • Bolt-on style mounting bracket eliminates welding time
  • Eliminates assembly and saves labor
• Enhanced Safety
  • Equipped with integrated dual counterbalance
    valve, virtually eliminating potential for
    catastrophic failure when valve is remotely
    located
• Provides Relieving Function
  • Optimized system performance
  • Reduced amount of leak points
  • Increased assembly speed saves labor
  • Provides protection against thermal expansion
• Offers Integral Load Holding
  • Positive load holding in case of pressure loss
  • Reduced lead points
• SAE Fittings
  • Provide significantly reduced leaking potential>
